Radio Configurations, RBS 2106 and RBS 2206
4.7.1 RBS 200 Expanded with 12–TRX Cabinet
Co-Siting with RBS 200 Using a Filter Combiner
Table 39 Expansion using filter combiner
Result
SCC
Original
SCC
Cabinet Combiner Antennas TMA Original
SCC
Basic
Configuration
Antennas
1 x 16 * 1x4 RBS 200 FCOMB (3) No 1x12 F9de_2.12 (2)
RBS 205 FCOMB (3) No F18d_2.12 (2)
RBS 205 FCOMB (3) M F18dt_2.12 (2)
RBS 205 FCOMB&DPX (2) No F18d_2.12 (2)
RBS 205 FCOMB (2) M F18dt_2.12 (2)
1x20
**
1x8 RBS 200 FCOMB (3) No 1x12 F9de_2.12 (2)
RBS 205 FCOMB (3) No F18d_2.12 (2)
RBS 205 FCOMB (3) M F18dt_2.12 (2)
RBS 205 FCOMB&DPX (2) No F18d_2.12 (2)
RBS 205 FCOMB (2) M F18dt_2.12 (2)
3x8
***
3x4 RBS 200 FCOMB (3) (3) (3) No 3x4 3 x F9de_2.4 (2) (2) (2)
**** RBS 205 FCOMB (3) (3) (3) No 3 x F18d_2.4 (2) (2) (2)
RBS 205 FCOMB (3) (3) (3) M 3 x F18dt_2.4 (2) (2) (2)
RBS 205 FCOMB&DPX (2) (2) (2) No 3 x F18d_2.4 (2) (2) (2)
RBS 205 FCOMB (2) (2) (2) M 3 x F18dt_2.4 (2) (2) (2)
M = Mandatory
* 1 x 6, 1 x 8, 1 x 10, 1 x 12 and 1 x 14 can be accomplished with a
partly-equipped expansion configuration.
** 1 x 10, 1 x 12, 1 x 14, 1 x 16 and 1 x 18 can be accomplished with
a partly-equipped expansion configuration.
*** 3 x 6 can be accomplished with a partly-equipped expansion
configuration.
**** When using TG-synchronization, only one RBS 200/RBS 205 can
act as master. Therefore the 3 x 4 configuration, which is three separate
RBSs, must be rebuilt to one single RBS, that is, all three sectors of the
RBS 200 must be connected to the same TMCB.
