erowa MTS - Product Identification and Specifications; MTS Base Plate Components Description

7
STANDARDIZATION
WORKHOLDING SYSTEMS
MTS Base Plate
ER-148220
1
2
3
4
P2
2. Bezeichnung der Teile
1) MTS Integral Chuck
M-P (2 x)
2) Zentrierkonus
3) Z-Auflagen
4) Luftpistolenventil
P2) Pneumatikanschluss,
G1/8",
Öffnen/Schliessen
2. Description of parts
1) MTS IntegralChuck
M-P (2 x)
2) Centering taper
3) Z-supports
4) Air jet valve
P2) Pneumatic connection,
G1/8",
open/close
DOC-146920-00
2. Désignation des éléments
1) Mandrin IntegralChuck
M-P MTS (2 x)
2) Cône de centrage
3) Appuis Z
4) Valve pour pistolet
pneumatique
P2) Raccordement Pneumati-
que, G1/8",
ouverture/fermeture
