Door 1 give access to the compartment of water pipes and
water side heat exchanger.
Door 2/3/4 give access to the hydraulic compartment and electrical parts
.
Door 1
Door 3
Fig. 8-4 doors of ECH030N
8.2 Opening the uint
Door 2
Door 4
By means of a detachable service panel, the maintenance personnel can easily access the interior components of the unit.
