ESAB Digimig Dual User Manual

24
SECTION 6 REPLACEMENT PARTS
RIGHT TORCH (J3) RECEPTACLE - 182W64 (C10, 11) CAPACITOR 672348
COVER - 30170* WARNING DECAL - 2091514*
WARNING DECAL - 995204*
(2) EH-10A DIGITAL MOTOR-GEAR UNIT ASSY. 679777 (See Fig. 6)
BASE - 678806
LEFT TORCH (J4) RECEPTACLE -
182W64
C16 CAPACITOR
672348
(2) ACCESSARY SUPPORT ASSY. 2 ROLL DRIVE (See Fig. 8) - 49V51
FRONT CONTROL SUPPORT - 30917
(SW1, 3, 5) SWITCH - 950087 
LIFTING BRACKET - 30916
CONTROL ASSY. 30913 (see Fig. 7)
6-POS. ROTARY SW. - 679914
Fig. 6-1. DigiMig Dual Wire Feeder, P/N 30912 (Front View)
