ESAB LAB 475 - 5) CONTROLS AND MAIN COMPONENTS; 5.1) Front Panel

1
4
3
7
6
5
2
8
9
10
5) CONTROLS AND MAIN COMPONENTS
5.1) Front Panel
1) ON/OFF switch:allows the operator to turn the source on and off.
2) Pilot Lamp:when on, indicates that the source is on.
3) Output NegativeTerminal :for welding cable connection.
4) Output PositiveTerminal :to connect the positive cablefor the wire feeder.
5) Handle:for adjusting the voltage read at the gauge or digital instrument.
LAB 320
LAB 475
19
