LKB 265
c=component designation in the circuit diagram
Item Qty Ord.No. Denomination Remark c
501 1 486 305--881 Circuit board AP1
502 5 455 226--005 Spacer
503 1 193 260--150 Connector 2--way XS3
2 193 260--152 Connector 4--way XS5,XS6
2 193 260--062 Connector 3--way XS4
1 193 260--063 Connector 4--way XS7
1 193 260--156 Connector 8--way XS9
504 1 191 954--101 Hose ø8/5
505 1 193 054--002 Solenoid valve 42V YV1
506 1 190 315--102 Hose ø 11/4,8
507 1 0408 594--04 Grommet
508 2 192 230--109 Cover ø 19mm
509 2 192 230--114 Cover ø 30mm
510 1 469 950--880 Cable inlet
511 1 162 781--002 Terminal 3--way XT1
1 486 364--880 Circuit board AP2
512 1 455 637--001 Control transformer 163 VA, 400--415V TC1
1 455 638--001 Control transformer 203 VA, 230--500V TC1
513 1 193 922--001 Contactor 400--415V KM1
1 193 924--001 Contactor 230--500V KM1
514 1 193 655--012 Terminal 12--way XT2
516 1 455 486--880 Tr ansformator Compl. 400--415V TM1
1 455 486--880 Transformator Compl. 230--500V TM1
517 1 455 815--880 Diode bridge Compl.
518 2 469 380--882 Capacitor 0,1 ←F 250V C1,C2
519 1 455 818--880 Inductor L1
520 1 368 593--001 Resistor R1
524 1 455 620--001 Frontpanel
525 3 Screw M8x25
526 8 Washer 16/8,4x1.5mm
527 6 219 504--305 Spring washer 16/8,2x0,9mm
528 3 Nut M8
530 1 321 229--003 Thermal cutout 110 _C ST1
192 058--101 Thermal compound For fitting cutout
