4
B
A
Assembly
GB
Assembly
1. Mount the actuator unit on the valve according to
user instruction 1.
2. Mount the flow temperature sensor on the pipe
using the supplied aluminium tape.
DE
Montage
1. Montieren Sie den Stellmotorregler auf den
Mischer, wie in Anleitung 1 beschrieben.
2. Befestigen Sie den Vorlauftemperaturhler
an der Rohrleitung mithilfe des mitgelieferten
Aluminiumklebebands.
PL
Montaż
1. Zamontuj siłownik na zaworze zgodnie z instrukcją
1.
2. Zamontuj czujnik temperatury zasilania na rurze
za pomocą dostarczonej taśmy aluminiowej.
SE
Montering
1. Montera ställdonsenheten på ventilen i enlighet
med bruksanvisning nr 1.
2. Montera framledningsgivaren på röret med hjälp
av medföljande aluminiumtejp.
RU
Установка
1. Установите привод на клапан согласно
инструкции пользователя 1.
2. Установите датчик температуры подачи на
трубе с помощью входящей в комплект поставки
алюминиевой ленты.
Montaje
1. Montar el actuador en la válvula según las
instrucciones del usuario.
2. Montar el sensor de temperatura de caudal en el
tubo con la ayuda de la cinta de aluminio provista.
