ESCALADE Atomic G01344W - Step 6: Leg Assembly; Attach Legs and Leg Levelers

©
2017 Escalade Sports
For Customer Service Call 1-888-996-2729
11
All Rights Reserved.
STEP 6
Attach P6-R Legs onto P1R, P2R Side Aprons and P3R, P4R End Aprons using H7,H8 Bolts
and H5 washers as shown in FIGURE 6. Use T2 Allen Wrench to tighten all P6R Legs.
Then screw P9 Leg Levelers into the bottom of each leg as shown in FIGURE 6.
PARTS REQUIRED:
4 pcs - P6R Leg with LED wire connection
4 pcs - P9 Leg Leveler8 pcs - H7 8 mm x 38 mm Allen Head Bolt
16 pcs - H5 8.5 mm x 22 mm Flat Washer
8 pcs - H8 8 mm x 50 mm Allen Head Bolt
P1R
P2
IMPORTANT NOTE:
The longer H8 Bolts are used to screw
into the Side Aprons.
The shorter H7 Bolts are used to screw
into the End Aprons.
FIGURE 6
P9
P6R
P6R
P6R
P3R
P4R
P6R
H7
H5
H8
Leave the
red and black
wires of every
Leg outside
Leave the
red and black
wires of every
Leg outside
