STEP 7
Connect the female plug of each leg to the male plug near apron corners, and carefully stow wires
into the corner as shown in
FIGURE 7 and Detail B.
FIGURE 7
P10
P12
P11
P11
P11
NOTE:Make sure slots on plugs are turned correctly
for correct installation.DO NOT FORCE THIS
CONNECTION and a flashlight will be very helpful to
study both the male plug and female Plug to insure
a correct connection.
Detail B
Snap Lock
Tab for
Snap Lock
CAUTION: Four strong adults are recommended to flip
the table as shown.
1. Grab the table on the ground.
2. Turn the table over.
3. Place it on all four feet at the same time on the ground.
To Next Page
