ESCALADE Atomic - Hardware Identification; Parts Identification

3
H1 = 8 pcs
H2 = 16 pcs
8.5 mm x 22 mm
8 mm x 35 mm
Allen Head Bolt
H5 = 16 pcs
M8 Lock Washer
Flat Washer
T1 = 1 pc
H3 = 8 pcs
8 mm x 40 mm
Allen Head Bolt
Allen Wrench
P1 = 1 pc
P2 = 2 pcs
P3 = 2 pcs
Left Leg
（with LED Light Feature） （with LED Light Feature）
Right Leg
Air Hockey Table Cabinet
Leg Leveler
P5 = 4 pcs
End Leg Panel
P4 = 2 pcs
HARDWARE IDENTIFIER
(To Scale)
(Not to Scale)
PARTS IDENTIFIER (Not to Scale)
3.5 mm x 18 mm
Phillips Round
Head Screw
H4 = 2 pcs
= 1 pc
Electronic Scorer
P6
Red Striker
A3 = 2 pcs
Red Puck
A4 = 2 pcs
A1 = 2 pcs
Blue LED Striker
Blue LED Puck
A2 = 2 pcs
USB Cable
（ Only used to charge
the A1 LED Strikers）
A5 = 1 pcs
