E S C A L A D E E X T
INSTRUMENT PANEL CLUSTER
The instrument panel cluster includes
these key features:
1. Tachometer
2. Engine Coolant Temperature Gage
3. Odometer/Driver Information
Center Display
4. Fuel Gage
5. Speedometer
6. Oil Pressure Warning Light
7. Charging System Warning Light
8. Safety Belt Reminder Light
9. Air Bag Readiness and
Warning Light
10. Anti-lock Brake System
Warning Light
11. Check Engine Light
12. Brake System Warning Light
13. Security Light
14. Lights On Reminder Light
15. Tire Pressure Warning Light
16. StabiliTrak Indicator Light
21
4
5
3
6
7
8
9
10 161511 12 13
NNoottee::
The instrument panel cluster is designed to let you know
about many important aspects of your vehicle’s operation. It is
important to read your Owner Manual and become familiar with
the information being relayed to you by the lights, gages and
indicators, as well as what action can be taken to ensure safety
and to prevent damage.
