39
32.
NOTE: Do not cover the Warning Label on the
front of the pole with the Pole Pad.
Post Screws
Figure 18
16
NOTE: Top of Pole Pad #48 should
cover Post Screws but remain
below Warning Label on the
front of the Pole.
Secure Post Pad (#39) to front of pole by wrapping straps
around pole and sticking to velcro on opposite side of Pad.
Post Pad should cover Post Screws but remain below
Warning Label on front of the Pole. See Figure 18. Make
sure to reposition Pole Pad if Sliding occurs.
