Escea DF700 - Freestanding Unit (DFS730) Installation; Product Dimensions; Hearth and Clearances; Locating the DFS730

45
G 
Product Dimensions
 Hearth and Clearances
A hearth is not required, however it may be used for decorave purposes or for protecon of sensive ooring.
The hearth should not obscure the air inlet of the re.


G3 
505mm
736mm*
381mm
124mm
753mm
368mm* 368mm*
*Measured from Console Body
756mm
175mm
315mm
50mm
50mm 50mm
51mm
