Escea DF700 - Flue Installation

G
47
G5 
The freestanding unit and ue system should be installed prior to the DF-Series replace being installed (for
horizontal terminaon for DFS730: see G6 on page 48).
 

 

 

 
 


 

 

 


 



 






 
manual
Note: Ensure a power supply is within 1m of the rear of the
appliance.
Ceiling Ring
230mm
Flue liner
2x Flexible
ue
Flexible ue clamped
to Flue Spigot Plate
Flue Liner
Rodent Guard
Ø265 mm
Ceiling hole
Power Flue Cable
1.2m F-F Liner
Hose band clamps
Roof Space
UVP Fan Unit
DFS730
Fireplace
Console
DF700
Fireplace
‘Dectite’ or
similar ashing
Ø230mm Flue Liner
Ø75mm Air
Flexi Flue
Ø100mm Exhaust
Flexi Flue
Powerflue
Cable
IN OUT
Cable
Tie
