ESCO EURO BEAD BREAKER Model #10107
Hydraulic Flow
Use the hydraulic ow information to help troubleshoot problems with the ESCO Euro Bead Breaker
The bead breaker works via an
air/hydraulic pump which supplies
hydraulic uid pressure to the clamping
cylinder. Fluid pressure is restricted to
the clamping cylinder by spring pressure
on the sequence ball and by the mated
surfaced of the uid return ball and its
seat. As the clamping rod moves out of
the cylinder, the jaw clamps rmly on the
rim.
The internal hydraulic pressure of the
clamping cylinder is sucient to
overcome the spring pressure against
the sequence ball. The ball is forced
away from the seat and pressure
increases inside the breaker cylinder.
