Important Notes
Error Codes
Below is a list of error codes which are shown
in error messages. The codes help diagnose
the cause of the error.
Error
Replace A critical issue has been reported
requiring component to be
replaced or repaired.
Check Connections and wiring of
component should be checked. If
problem persists there may be an
issue with component.
High Temp Component is too hot. Mounting
it in a cooler location may be
necessary.
Hi Volt Power supply voltage is too high.
Voltage must be between 10.5 –
16 V DC.
Lo Volt Power supply voltage is too low.
Voltage must be between 10.5 –
16 V DC.
Component
IF Interface
FR Front Radar Receiver
RR Rear Radar Receiver
GR GPS Receiver
SB Shifter Bridge Box
S1 Shifter Sensor 1
S2 Shifter Sensor 2
S3 Shifter Sensor 3
S4 Shifter Sensor 4
S5 Shifter Sensor 5
S6 Shifter Sensor 6
For information about accessing the error code
log, visit the “User Manuals” section of the
EscortRadar.com website.
Installation Warnings
1 It is recommended that you have a
professional install your new ESCORT MAX Ci .
Installation of this system requires experience
and expertise in automotive electronics. If you
are unfamiliar with automotive electronics, car
audio specialists and many car dealers can
install your ESCORT MAX Ci for you.
2 Attempting to install this product without
expertise in automotive electronics installation
can cause personal injury or damage to your
vehicle.
3 If your vehicle is damaged during
installation its safety systems may be
compromised, which could cause personal
injury or property damage.
4 Improper installation may void ESCORT
MAX CI’s warranty.
Performance Warning
To get the best performance possible, the
mounting location of the radar receiver is
critical. Although radar signals will pass
through some types of plastic, mounting
the radar receiver so that it has a clear
“view” of the road will ensure maximum
warning.
Since Laser signals will not pass through
objects, including most plastics, it is critical
that the Laser Shifters are mounted
perfectly level and have an unobstructed
“view” of the road.
E Read This First
Please read these instructions in their entirety
before starting your installation.
For the easiest, trouble-free installation, install
the interface first and wire it to a 12-volt
switched circuit.
Then, before installing the other components,
plug all of them into the interface and power
up the unit to confirm proper operation.
