11
ENGLISH
Component video output terminals
Use commercially available BNC coaxial cables to connect
the unit to the component video inputs of a suitably-
equipped television or monitor to enjoy a high-quality
picture. Use these terminals in preference to S-Video or
composite video connections.
<
Note that these terminals cannot be connected to high-
definition component (Y/P
B/PR) terminals.
<
If the television or monitor is equipped only with RCA (pin)
jacks for component video, a suitable adaptor cable or
adaptors should be used.
S-Video output terminal
Use a commercially available S-Video cable to connect the
unit to the S-Video input of a suitably-equipped television or
monitor. Use this connection in preference to a composite
video connection.
Composite video output terminal
Use a commercially available RCA (pin) video cable to
connect the unit to the composite video connector of a
television or monitor. Use this connection only if no other
video connection method is available.
E
D
C
< Adjust the video aspect ratio to match that of the television
(see page 38) .
< If the component video terminals or the D1/D2 terminal are
used to connect the unit to a television with progressive-
scan capabilities, the output can be set to match this (see
page 39).
<
This unit adopts analog copy protection features. If the unit
is connected to a TV through a VCR (video cassette
recorder), the resulting playback may be affected.
Connect
the unit directly to the television.
< In all cases, use the highest quality cables for the best
possible picture.
DVI-D video output terminal
Use a commercially available DVI-D output cable to connect
the unit to a DVI/HDCP compatible television or monitor.
DVI output formats
480p (NTSC) or 576p (PAL), 720p, 1080i
<
The television connected in this way must be DVI/HDCP
compatible. Use with incompatible televisions may
sometimes result in the playback picture not being visible.
<
See page 26 for further details on DVI output formats.
<
Make sure that you read and understand the documentation
provided with the DVI component, as well as this unit’s
documentation.
D1/D2 video output terminals (component)
By using a commercially available D terminal cable to
connect the unit to a “D compatible” (D1, D2, D3 or D4)
television or monitor, high-quality images, equivalent to
those achieved using component video, will be displayed.
B
A
D terminal and signal format (NTSC/PAL)
480i/576i 480p/576p
(525i/625i) (525p/625p)
D1 terminal
X
D2 terminal
D3 terminal
D4 terminal
Numbers in parentheses show the number of scan lines
i = interlace (flyback)
p = progressive scan
