2 Schematic Checklist
• USB - GPIO18 and GPIO19 are USB pins. The pull-up value of a USB pin is controlled by the pin’s pull-up
value together with USB pull-up value. If any of the two pull-up values is 1, the pin’s pull-up resistor will be
enabled. The pull-up resistors of USB pins are controlled by USB_SERIAL_JTAG_DP_PULLUP bit.
• G - These pins have glitches during power-up. See details in Table 5.
Table 5: PowerUp Glitches on Pins
Typical Time Period
Pin Glitch
1
(ns)
MTCK Low-level glitch 5
MTDO Low-level glitch 5
GPIO10 Low-level glitch 5
U0RXD Low-level glitch 5
GPIO18 Pull-up glitch 50000
1
Low-level glitch: the pin is at a low level during the time period;
High-level glitch: the pin is at a high level during the time period;
Pull-up glitch: the pin is pulled up during the time period;
Pull-down glitch: the pin is pulled down during the time period.
