TECHNICAL DATA
The cooker data plate is located behind the cast oven door.
Warning: This appliance is not suitable for installation in a shared flue system
TECHNICAL INFORMATION
Nominal heat output
5.0 kW
Minimum chimney
draught
12Pa
Combustion air
requirements
29 m
3
/h
Mean flue gas
temperature
216remote
O
C
Weight of appliance
400kg
Flue gas mass flow
10g/s
Net efficiency
82.3%
Seasonal efficiency
72.3%
ERP rating
A+
Energy Index
109
CHIMNEY AND FLUE INFORMATION
The successful operation of the cooking appliance relies on the adequate
performance of the chimney to which it is connected. The following chimney
guidelines must be followed:
• It should be installed and commissioned in accordance with BS EN
15287-1:2007
• It should have an internal cross section of no less than 320cm2
(200mm dia.) (If a flue liner is used, it should be 150mm (6’’)
diameter and be made of suitable material for burning wood). A
Flue with a diameter of 150mm (6’’), is required to connect to the
cooker.
• Voids in the chimney should be avoided, as these will prevent a
steady flue draught. The appliance flue pipe should pass beyond
the narrowing of the chimney.
• Terminate at least 1m above roof level so that the chimney does
not terminate in a pressure zone.
• If the appliance is installed as a freestanding appliance, it should
not support any part of the chimney.
• Be free from cracks, severe bends, voids, and obstructions.
• Be connected to this one appliance only.
• New chimneys must be in accordance with local regulations.
