Essilor Instruments VISIOSMART 500 - Device Overview



 
 
 
1
Stationary forehead rest*
1
2
Eyepieces for far vision
3
Eyepieces for near vision
4
External screen
5
Handle
6
Connector for peripheral
devices
7
Height adjustment button


4
3

1
o

1
Hatch (access to the inside of
the device)
2
ON/OFF button
3
24V power socket
4
Outlet for push button*
2
5
Outlet for USB uploading
6
Headset outlet


1
3 4



