Page 9 of 10 D A T A S H E E T 85005-0131
Not to be used for installation purposes. Issue 7
Note:
For earthquake anchorage, including detailed mounting weights and
center of gravity detail, please refer to Seismic Application Guide 3101676-
EN. Approval of panel anchorage to site structure may require local AHJ,
structural, or civil engineer review.
Standby batteries must be mounted externally from fire panel in separately
mounted BC-1 enclosure. Order BC-1 aand BC-1EQ separately.
Model Description Ship wt.
278A-REL
Manual releasing station (double-action).
English markings, black text on yellow
polycarbonate body.
1.0 (0.45)
RELA-ABT
Manual Abort Station. English markings,
black text on yellow polycarbonate body.
1.0 (0.45)
RELA-SRV-1
Service Disconnect Switch. One n/c contact
and one n/o contact. English markings, white
text on blue polycarbonate body.
1.0 (0.45)
RELA-EOL
Polarized end-of-line relay. English markings
on stainless steel cover.
0.2 (0.1)
SIGA-UIO2R Universal Module Board w/Riser Inputs - Two
Module Positions
0.32 (0.15)
SIGA-UIO6R Universal Module Board w/Riser Inputs - Six
Module Positions
0.62 (0.28)
SIGA-UIO6 Universal Module Board - Six Module
Positions
0.56 (0.25)
Accessories
GCI Graphic Annunciator Driver, provides outputs
for common indicators and 32 alarm/supv
zones as well as inputs for common switches.
Provided with a snap track for mounting in
custom graphic enclosures.
CTM City Tie Module. Provides connection to a
local energy fire alarm box.
0.6 (0.3)
RPM Reverse Polarity Module 3.0 (1.36)
BC-1 Battery Cabinet. 14.0" x 18.25" x 7.25". Holds
2 12V24A batteries.
50.0 (22.7)
BC-1R Battery Cabinet - Red. 14.0" x 18.25" x 7.25".
Holds 2 12V24A batteries.
50.0 (22.7)
MFC-A Multifunction Fire Cabinet, 8" x 14" x 3.5" -
RED.
20.6 (9.4)
PT-1S System Printer - Desktop style. 36.6 (16.6)
BC-1EQ Seismic hardening Kit for iO series panels.
Includes battery hardening for BC-1 enclosure
and components to harden panel internal
components. See note.
