1. Unscrew top hinge cover and disconnect
connectors of door switch and harness.
2. Unscrew top hinge.
3. Remove the pin with a screwdriver and flip
the hinge bracket. Then refit the pin
to hinge bracket.
4. Move door switch from right hinge cover
to left hinge cover in accessary bag.
5. Move top left cover to
right side.
6. Take off the upper door, take out the screw from
the middle hinge by cross screwdriver, then take
off the lower door.
