13. Install the lower door, adjust and fix the
middle hinge onto the cabinet.
14. Replace upper door, please ensure the door align
with the cabinet to make sure door gasket seal the
cabinet tightly. Then connect door with cabinet by
tightly fixed top hinge.
15. Connect harnesses from door and cabinet.
Then replace top hinge cover. Before screw
the cover, connect terminals of door switch.
IV. INSTALLATION
Space Requirement
• Keep enough space of door open.
• Keep at least 50mm gap at two sides.
ETA275690000E
ETA275690010E
A 600 mm
B 600 mm
C 1850 mm
D 50 mm
E 50 mm
F 50 mm
G 1200 mm
H 1200 mm
I 135 °
