12 SmartPack User Manual
Start / Stop a Sequence
Step 1: Scroll to Sequencer, press .
• Start the sequence, scroll to Start Sequence and press . Sequence
Started will briefly display and the control symbol on the LCD will display
the “S”.
• Stop the sequence, scroll to Stop Sequence and press . Sequence
Stopped with briefly display and the control symbol on the LCD will no
longer display the “S”.
Dimmer Curves
SmartPack is capable of dimming multiple load types including incandescent, low voltage
and 2-wire fluorescent. SmartPack provides five user-selectable dimmer output curves to
choose:
• IES modified square law
• Linear
• Switched (50% threshold, non-regulated)
• Fluorescent with adjustable cut-off
• Adjustable pre-heat
Set Dimmer Curve
Step 1: Scroll to Dimmer Curves, press .
Step 2: Use + or - to select the specific dimmer number (or ALL) to be modified. Press .
Step 3: Use + or - to scroll through the five options, press to select the output curve of
choice.
a: If Fluorescent output curve is selected you must specify the Start Voltage.
• Fluorescent circuits provide a dimmable output in the 5% to 100% control
range. Trim the minimum RMS output voltage to match your specific
ballast.
• The default voltage is 47% of your mains voltage. Use + or - to increase or
decrease the Start Voltage value.
• Consult the ballast manufacturer’s documentation for the appropriate
minimum start voltage.
b: If Preheat output curve us selected you must specify the preheat level
(allowable 0% - 20% range).
Note:
The sequence will start at preset 1 and run for a user configured number of steps.
If the sequence is not configured to loop, the sequence will stop. If the sequence
is set to loop, the sequence will continue looping until the sequence is deactivated.
