4 SmartPack User Manual
SmartPack 19” Portable
The SmartPack Portable dimmer packs are designed in a rugged 19-inch 2-space rack
mount package. Ships standard with SmartLink™ enabled for total versatility.
• UL listed SmartPack Portable dimming packs are available with either six 20A dimmers
or twelve 10A dimmers.
• CE marked SmartPack Portable dimming packs are available with either three 25A
dimmers, six 15A dimmers, or twelve 10A dimmers.
In addition the SmartPack 19” Portable pack is available with a wide variety of output panel
options to fit industry needs.
UL Rear Panel Options CE Rear Panel Options
6 Channel 12 Channel 3 Channel 6 Channel 12 Channel
Edison Edison Harting Schuko
PowerCon
®
Stage Pin Stage Pin Multi-pin NF French Harting Multipin
Twist-Lock
®
PowerCon
®
Terminal Output Swiss Socapex Multipin
Japanese Twist-Lock Dual 6 circuit
Multipin
CEE 32A, 230V UK 15A Roundpin Terminal Output
PowerCon
®
Term i nal St r ip
Power Con
®
Single 6 circuit
Multipin
Wireland GST18
Terminal Strip Harting
Socapex
Model Part Number Channels Breaker Voltage/Supply Notes
SL620 7020A1000 6 20A
120/240 VAC 1Phase
120/208 VAC 3Phase
with output panel and SmartLink
enabled
SL1210 7020A1001 12 10A with output panel and SmartLink
enabled
Model Part Number
Channel
Count
Breaker
Type
Voltage/Supply Notes
SL325-ND 7021A1106-xx 3 25A ND
230-240 VAC 47-63Hz
with 2-pole breakers and output
panel
SL615 7020A1002-xx 6 15A with output panel and SmartLink
enabled
SL615-ND 7020A1004-xx 6 15A ND with 2-pole breakers, output panel
and SmartLink enabled
SL1210 7020A1003-xx 12 10A with output panel and SmartLink
enabled
SL1210-ND 7020A1005-xx 12 10A ND with 2-pole breakers, output panel
and SmartLink enabled
