2-1/2” (65mm)
in the exact
center of the stud.
Fig. 3a
Fig. 3b
Wood stud walls
Use a wrench, the two long bolts (A), and Washers (C), to attach the wall mount to the wall.
Do not use wall anchors in wood stud walls.
5. Use the magnet level on the front of the mounting plate to level the wall mount, repositioning as
necessary, then securely tighten the bolts. Do not overtighten.
