Etec EXSM2455 - Concrete Wall

7
two
B
2.5”
65
2.5” (65mm)
Concrete Wall
Use a wrench the two long bolts (A), and Washers (C), to attach the wall mount to the wall.
Fig. 3d
5. Use the magnet level on the front of the mounting plate to level the wall mount, repositioning
as necessary, then securely tighten the bolts.
TOP
A
B
C
