DMX channel allocation:
1
1
0-255
X-axis (PAN)
2
2
0-255
Y-axis (TILT)
3
0-255
XY speed
3
4
0-255
Master dimmer
4
5
0-255
red
5
6
0-255
green
6
7
0-255
blue
7
8
0-255
White
8
9
0-9
No strobe
10-250 Strobe van slow -> fast
251-255 Strobe 100%
10
0-255 0-10 No Function 91-100 G+W
11-20 R 101-110 R+W
21-30 G 111-120 R+G+B
31-40 B 121-130 R+G+B
41-50 W 131-140 G+B+W
51-60 R+G 141-150 R+G+B+W
61-70 G+B 151-200 Farbwechsel
71-80 B+W 201-255 Farbübergänge
81-90 R+B
11
0-255 Color change + color transitions Speed for channel 10
12
X- axis (PAN) fine
