Page | 8
Flash Rate: (min) 1 Hz
Flash Rate: (max) 25 Hz
PAN range: 540 °
TILT area: 270°
Width: [cm] 33
Depth: [cm] 23
Weight: [kg] 9.65
Product Overview
:
1. LED Diode
2. Display
3. Button: Mode, Up, Down, Enter
4. DMX linking IN/OUT
5. Fuse
6. 6. ON / OFF switch
7. PowerCON IN / OUT
Functions and settings:
LCD display
MENU: Function mode selection, such as DMX, Master / Slave, Auto, Sound Mode and Brightness
settings
DOWN/UP: Previous or Next function
1.
6.
7.
2.
3.
4.
5.
