EETTHHOOSS 88440000
INSTRUCTION MANUAL
UUnnppaacckkiinngg tthhee TTeesstteerr
Your Ethos 8400 Multifunction Tester comes complete with:
D
ESCRIPTION PART NO QTY
Multifunction Tester Ethos 8400 1
Instruction Manual 1
3 Wire Split Lead Ethos 2125 1
Assembly with Probes +
Crocodile Clips Brown/Blue/Green
13 Amp Mains Lead to 4mm Ethos 2126 1
Connections Brown/Blue/Green
Remote Switch Probe Ethos 2127 1
AA LR6 Alkaline Battery Duracell 6
Heavy Duty Carry Case Ethos 8001 1
Neck Strap Ethos 2128 1
Certificate of Calibration 1
Warranty Registration Card (terms of 3 year warranty) 1
All the parts listed above are included in the carry case.
6
EETTHHOOSS 88440000
INSTRUCTION MANUAL
OOppeerraattiinngg tthhee EEtthhooss 88440000
To insert batteries ensure the instrument is switched
off and no test leads are connected.
Remove battery cover from base of unit, insert
batteries into holder ensuring correct polarity.
Replace cover.
Always use good quality LR6 AA Alkaline Batteries.
Re-chargeable batteries are not suitable.
Battery power level indicated on the colour display by the symbol shown.
Please dispose of your batteries carefully.
Batteries are made from important resources and chemicals, including
lead, cadmium, zinc, lithium and mercury. If batteries are disposed of as
normal waste, they’ll be taken to a landfill site and those resources will be
lost and will contribute to the pollution of the environment. Recycling is
one way you can help the environment and you should dispose of used
batteries separately from other waste, using local collection and recycling
schemes available.
To clean the tester use a damp cloth do not use any solvents. Do not allow
any water ingress and ensure tester is fully dry before use
When replacing/removing fuse from inside battery compartment do not use any sharp
implements for this task.
OOvveerrvviieeww
Front panel and controls
