Questions and Answers

B
Brenda LambertAug 12, 2025
What to do if my Etnyre Black-Topper Construction Equipment pump will not turn or turns slowly?
- V
  vgarciaAug 12, 2025
  If your Etnyre Construction Equipment pump doesn't turn or turns slowly, there are several possible causes: * The material in the tank or pump might be below the necessary pumping temperature. In this case, heat the material to the proper pump temperature. * There could be an air leak in the suction line. Locate and repair the leak. * The hydraulic system pressure might be low. Increase the pressure. * The hydraulic reservoir might have low oil. Add hydraulic oil to the correct level. * The spray bar valves might be set improperly. Correct the spray bar valve settings. * The hydraulic motor may be defective. Check for excessive case drain in the motor.
J
Jeremy KaneAug 15, 2025
Why is the hydraulic oil overheating in my Etnyre Construction Equipment?
- D
  Danielle HarmonAug 16, 2025
  If the hydraulic oil in your Etnyre Construction Equipment is overheating, consider the following possible causes and solutions: * The material in the tank or pump might be below the correct pumping temperature. Heat the material to the proper pump temperature. * There might be an air leak in the suction line from the reservoir to the filter and the inlet of the charge pump. Find and fix the leak. * The oil level in the hydraulic reservoir could be low. Add hydraulic oil to the correct level. * The spray bar valves may be set incorrectly. Make sure the spray bar valve settings are correct.
C
Charles VasquezAug 19, 2025
How to fix spray streaks from my Etnyre Construction Equipment?
- J
  Jonathan LozanoAug 20, 2025
  If you notice spray streaks when using your Etnyre Construction Equipment, it could be due to several reasons: * The pump speed might be too slow. Increase the pump speed. * The nozzles might not be at the correct angle. Adjust the angle of the nozzles. * The spray bar might be at an improper height above the ground. Adjust the spray bar height. * The material temperature might be too low. Heat the material to the correct temperature.
A
Angela McdonaldAug 25, 2025
What to do if the spray lacks pressure on my Etnyre Black-Topper Construction Equipment?
- N
  Nicholas ChavezAug 25, 2025
  If your Etnyre Construction Equipment spray lacks pressure, it could be due to: * The pump speed being too slow. Adjust the pump speed. * One or more control valves being in the incorrect position, not fully opened or closed, or leaking. Check the position of all control valves, ensure they are fully opened or closed, and repair any leaking valves. * The suction strainer being plugged. Clean the suction strainer.
R
rosejoanAug 27, 2025
Why does the application rate vary on my Etnyre Construction Equipment?
- S
  Steven ObrienAug 27, 2025
  If the application rate varies with your Etnyre Construction Equipment, here’s what might be happening: * The quantity of material in the tank might not be measured accurately. Use the Etnyre measuring stick for accurate readings, and ensure the tank is level when measuring. * The suction strainer might be plugged. Clean the suction strainer regularly. * The hydrostatic controls may not be firmly positioned. Ensure that all controls are firmly locked in place. * The suck back valves may not be fully closed. Ensure the valve is closed.
B
brandonwilliamsAug 30, 2025
How to prevent spray fogs from my Etnyre Construction Equipment?
- D
  Derrick KimAug 30, 2025
  If your Etnyre Construction Equipment is spraying fogs, it means the pump speed is too fast for the nozzle size. You can lower the pump speed or change the nozzles.
K
Kelly MartinezSep 3, 2025
Why do all nozzles not cut off spray on my Etnyre Construction Equipment?
- G
  George Thomas PhDSep 3, 2025
  If all nozzles on your Etnyre Construction Equipment do not cut off spray, it is because the spray bar linkages are not adjusted correctly. To resolve this, adjust the linkage.
M
Mary SchmidtSep 7, 2025
What to do if spray bar supply tube ball joints leak on my Etnyre Construction Equipment?
- C
  Clinton WallaceSep 7, 2025
  If the spray bar supply tube ball joints on your Etnyre Construction Equipment are leaking, the ball joint O-ring is likely loose. Replace the ball joint O-ring to fix this issue.

Summary

Warranty

Warranty Coverage and Limitations

Details the twelve-month warranty, obligations, exclusions, and conditions for the product.

General Safety Instructions

Safety Precautions and Hazard Levels

Defines signal words (DANGER, WARNING, CAUTION) and hazard seriousness levels.

Fluoroelastomer Handling and Hazards

Guidelines for handling fluoroelastomers, potential hazards, and neutralization procedures.

Fire and Explosion Prevention

Safety measures to prevent fires and explosions related to burners and flammable materials.

Introduction

Reporting Safety Defects

Instructions for reporting vehicle defects to NHTSA and Etnyre for safety investigations.

Component Location and Identification

Overview of rear, side, and spray bar components with diagrams.

Preparing for Operation

Setup Screen Parameters

Details adjustable parameters on Setup Page 1, including Pump Threshold and Minimum Flow.

Machine Calibrations

Procedures for calibrating components like Smart Cylinders, Pump EDC, Radar, and Tank Level Sensor.

Display Screen Settings

Configuration options for the touchscreen display, including backlight, touch point, and screen saver.

Operation Modes

Main Controls and Home Screen

Overview of the main controls, operation modes, and pump control on the Home screen.

Burner Control and Ignition

Instructions for operating the burners, adjusting temperature, and ignition procedures.

Spraying Through the Spray Bar

Procedures for setting up and performing spraying operations using the spray bar.

Suck Back Operation

Steps for performing suck back operations, including handspray suckback and override features.

Troubleshooting

Common Spray Issues and Solutions

Table of common spray problems (fogs, streaks, pressure) and their remedies.

Pump and Hydraulic System Troubleshooting

Addresses pump issues (not turning, slow, overheating) and hydraulic oil problems.

Maintenance

Gun Assembly and Electrode Settings

Procedures for installing the gun assembly and setting electrodes for proper operation.

Etnyre P-15 Pump Servicing

Detailed instructions for vacuum checks, pump disassembly, inspection, and impeller installation.

Hydraulic Fluid Requirements and Contamination

Information on fluid quality, viscosity, temperature limits, and contamination control for hydraulic systems.

Electrical Schematic

Cab Control Box Wiring Diagrams

Detailed wiring diagrams for the cab control box components and connections.

Rear Control Box and Options Wiring Diagrams

Wiring schematics for the rear control box, options, and various modules.

Appendices

Appendix A - Valve Abbreviations (Standard Bar)

List of abbreviations for valve functions related to the standard spray bar.

Appendix B - Valve Abbreviations (Variable Width Bar)

List of abbreviations for valve functions specific to the variable width spray bar.

Appendix C - USB Application Update

Step-by-step guide for updating the touchscreen and computer software via USB.

Appendix D - Default GPM & LPM Chart

Table of default flow rates in Gallons Per Minute (GPM) and Liters Per Minute (LPM) for various operation modes.

Etnyre Spraybar Nozzles

Nozzle Part Numbers and Flow Rate Specifications

Catalog of spraybar nozzles with part numbers, descriptions, and application flow rates.

Serial Number Plate Location

Decimal Equivalent Chart

Table providing decimal equivalents for fractional measurements.
