battery
fuse
fuse
Remote
battery
fuse
fuse
Remote
fuse
The power connection can also be mounted in an alternative way as shown below.
It is more secure with high currents. Make sure the clamps are fixed tightly.
FUSES HAVE TBE MOUNTED ON THE FIRST 30 CM (BETTER CLOSER)
COMING FROM THE BATTERY!
See diagram below.
SPEAKER WIRING & POWER CONNECTION (FA 5000)
9
