Eubank EAA/EGA Wall Mount AC Installation & Operation Manual
05/2023 Rev.8
2.3.1 – Programming Menu Conguration
1. To Enter Programming Mode:
• Press and hold the Menu button for 5 seconds until P-01 is displayed.
2. While in Programming Mode main menu:
• Press the Menu button to enter the displayed parameter menu.
• Press the Up/Down buttons to adjust the current parameter number.
• The current parameter number will be displayed seven segments alternating showing "P-"
and the number every 0.5s.
3. While in parameter menu:
• The current parameter selection will be displayed seven segments.
• Press the Menu button to save the current parameter selection return to the programming
main menu.
• Press the Up/Down buttons to adjust the current parameter selection.
4. To exit programming mode, press and hold the Mode and Up buttons while in the programming
main menu.
• Press and hold the Menu button for 5 seconds.
• Note: The control will automatically exit the programming mode after 2 minutes with no
activity.
Note: 100 will be displayed by alternating between "1" and "00" every 0.5s.
Conguration Menu
Menu
Setting
Name Default Selections General Description
1 AC/HP Select AC AC, HP HP = Heat Pump Unit, AC = AC Unit
2 IBM Select P P, dC P = PWM, dC = 0-10V
3 FAN PURGE 90 N, 10-90 Indoor Blower off delay in seconds
4 IBM Y1 Set 80 40-100
“G” Fan only and “Y1” 1st Stage Cooling Indoor Blower
Speed Setting
5 IBM Y2 Set 100 40-100 “Y2” 2nd Stage Cooling Indoor Blower Speed Setting
6 OFM Select P P, dC P = PWM, dC = 0-10V
7 OFM Set 80 65-100 Outdoor Fan Motor Max Speed setting
8 Defrost Timer 30 30, 60, 90 Defrost cycle timer in minutes
9 EHDD select Y Y, n CAN ONLY BE "Y" IF SCKT IS "N"
10 SCKT select n Y, n SCKT= Y OVERRIDES EHDD
11 ODS set 50 0-70 Outdoor Sensor for HP or Econo. Dry Bulb Setpoint
12 ECONO select n Y, n n = Disabled (No Econo.), Y = Enabled (W/Econo.)
13 Sensor Type EN EN or DB Economizer sensor type selection EN= Enthalpy, DB = Dry Bulb
14 ECONO set d A-E
Selections A=73F, B=70F, C= 67F, D =63F E= 55F all @
50%RH (Only available if EN sensor type is se-lected)
15 MIN POS 20 20-100 Sets the damper position for Minimum Open
16 W2 speed 100 70-100 Sets the Indoor Blower Speed for Electric Heat
17 Dehum speed 80 60-100 Sets the Indoor Blower Speed for Dehumidication
18 DS calibration 0 -18 Defrost Sensor Calibration
19 SAS calibration 0 -18 Supply Air Sensor Calibration
20 T'STAT Select H H, C H = hardwired 24V Tstat, C = communicating Tstat
21 Modbus ID 1 36161 Sets the Modbus ID for the unit
22 Modbus BAUD rate 19 9.6, 19 Available Baud Rates 9.6 = 9600, 19 = 19200
23 Modbus timeout 25 21916 Communications Timeout in minutes
24 Test n Y, n When set to “Y” all timers are reduced for testing
25 SW version number N/A N/A Displays the current version software
