8
Item number 11559
Bicycle rack "AMBER I" for trailer tow bar
Contents
1. Proper use of the product 8
2. Scope of delivery 8
3. Speci cations 9
4. Tow bar requirements 9
5. Safety precautions 9
6. Operating instructions 10
6.1 Mounting the bicycle rack 10
6.1.1 Mounting the wheel rails 10
6.1.2 Mounting the lamp mount 10
6.1.3 Mounting the U-bracket 11
6.1.4 Mounting the frame holder 11
6.1.5 Mounting the license plate holder 11
6.1.6 Laying the electrical cables 12
6.1.7 Mounting the short tensioning strap 12
6.1.8 Mounting the plastic cover 12
6.2 Mounting the bicycle rack on the trailer tow bar 12
6.3 Mounting the bicycle to the bicycle rack 13
7. Maintenance and care 13
8. Notes regarding environmental protection 14
9. Contact information 14
WARNING
Please read the operating instructions carefully prior to use and observe all safety instructions!
Not observing such may lead to personal injury, damage to the device or to your property!
Store the original packaging, the receipt and these instructions so that they may be consulted at a later date! When passing on the
product, please include these operating instructions as well.
Please check the contents of package for integrity and completeness prior to use!
1. Proper use of the product
This bicycle rack is mounted to the trailer tow bar of a car and is designed for the transportation of one bicycle.
This device is not designed to be used by children or persons with limited mental abilities or without experience and/or lack of required specia-
list knowledge. Keep children away from the device.
The device is not designated for commercial use.
Use according to the intended purpose also includes the observance of all information in these operating instructions, particularly the observa-
nce of the safety notes. Any other utilisation is considered to be contrary to the intended purpose and may lead to material damage or personal
injuries. EAL GmbH assumes no liability for damage resulting from improper use.
2. Scope of delivery
1 x Base frame 4 x Lock screw M6 x 50 [mm]
2 x Wheel rail halves 4 x Washer 17.8 x 6.5 x 1.1 [mm]
1 x Lamp mount set 4 x Nut M6
1 x U-bracket 1 x Cross-headed screw M5 x 12 [mm]
1 x Frame holder, short 1 x Washer 9.8 x 5.4 x 0.9 [mm]
1 x Plastic cover 2 x Cross-headed screw M5 x 35 [mm]
3 x Tensioning strap, short 2 x Spring washer 8.1 x 5.5 x 1.2 [mm]
1 x Safety strap 2 x Washer 9.7 x 5.3 x 0.9 [mm]
1 x License plate holder 2 x Lock screw M8 x 60 [mm]
1 x Operating instructions 2 x Washer 15.8 x 8.5 x 1.1 [mm]
1 x Permit 2 x Knob nut M8
1 x Padlock with key Cable ties
