INSTRUCTIONS FOR THE USER
HOW TO CLEAN THE INNER OVEN DOOR GLASS
2QHRIWKHIHDWXUHVRIRXUFRRNHUVLVWKDWWKHLQQHU
oven door glass can be easily removed for cleaning
without the aid of specialized personnel. Just open the
oven door and remove the support securing the glass
¿JQ).
ATTENTION!!
This operation can be done also with the door
ÀWWHGRQDSSOLDQFHEXWLQWKLVZD\SD\DWWHQWLRQ
that when the glass is pull upwards, the force of
the hinges can close the door roughly.
OVEN DOOR REMOVAL
The oven door can be removed to give easier access to
WKHRYHQZKHQFOHDQLQJ7RUHPRYHSURFHHGDVIROORZV
• Open the oven door and insert rivet or nail (R) in the
KROH)RIWKHKLQJH¿J
3DUWLDOO\FORVHWKHGRRUIRUFLQJLWXSZDUGVDWWKH
same time to free stop tooth and hinge sector.
• Once the hinge is free, pull the door forwards tilting
it slightly upwards to free sector.
• To reassemble proceed in the reverse order,
paying attention to the correct position of sectors.
5(3/$&,1*7+(29(1/$03ÀJ
Ensure the appliance is switched off before
replacing the lamp to avoid the possibility of
electric shock..
In the event one or both oven lamps need replacing, the
QHZODPSVPXVWFRPSO\ZLWKWKHIROORZLQJUHTXLVLWHV
:9a+](DQGPXVWEHUHVLVWDQW
WRKLJKWHPSHUDWXUH&
7RFKDQJHWKHRYHQODPSIROORZWKHLQVWUXFWLRQV
• Draw out the side guide rails as described above.
Then, remove the glass protection cap (V) from
WKHEXOEVRFNHWOLIWLQJLWZLWKDVFUHZGULYHUSODFHG
between the cap and the oven wall and replace the
ODPS/)LWWKHDFFHVVRULHVEDFNLQUHYHUVHRUGHU
OVEN SEAL
The oven seal guarantees the correct functioning
RIWKHRYHQ:HUHFRPPHQG\RX
• clean it, avoiding abrasive tools or products.
FKHFNLWVVWDWHQRZDQGWKHQ
If the oven door seal has become hard or is
damaged, contact our Service Centre and avoid
using the oven until it has been repaired.
12
13
Q
MAINTENANCE SCHEDULE
NO REGULAR MAINTENANCE IS REQUIRED
EXCEPT FOR CLEANING
