Installing the window kit
Your window kit has been designed to fit most standard ‘horizontal’ and
‘vertical’ window applications, but for certain types of windows it may be
necessary for you to improvise/modify some aspects of the installation
procedure.
• Adjust the window slider to the length of a horizontally (or height of a
vertically) opening window (Fig. 10).
• Fit the slider to the bottom of the window sill (or to the side of the window, if
it opens vertically), then close the window.
• Fit the exhaust hose connector (window end) through the opening to the
outside (Fig. 11 and Fig. 12), making sure to observe the required 30 cm
clearances between the body and walls or other objects. Ensure at least
1 m between the unit and any television or radio to avoid electromagnetic
interference.
Installation (Cont.)
Fig. 10
Fig. 11 Fig. 12
