• Do NOT install/use the appliance in the following areas:
– outdoors or where water is likely to splash
– near a bath, shower, laundry basin or swimming pool
– in an area where oil is likely to splash
– near a hot gas or electric burner, or sources of fire
– near sources of heat, or exposed to direct sunlight
– in an area where furniture or other objects can obstruct the airflow
– in the presence of flammable substances or vapour such as alcohol,
insecticides, petrol, etc.
– at a dry cleaner’s premises.
• Clearances: There must be a clearance of at least 30 cm between
the appliance and any walls, furniture, curtains or any other obstacles.
Maintaining this minimum 30 cm clearance is essential; failure to keep that
distance can result in the unit malfunctioning or causing injury.
• Window application: The air exhaust can be installed in a vertical or
horizontal sliding window (refer to Fig. 1 and Fig. 2, below).
• Air exhaust installation instructions follow on pages 12–14. Keep the
length of the air exhaust hose to the minimum length necessary during
operation.
• Upright position: Place the unit on a flat surface to reduce the risk of it tipping
over. Do not tilt the unit, always keep it upright during installation and use.
• Misuse: We accept no responsibility for any eventual injuries or damages
caused by improper installation, faulty use or failure to follow the instructions.
• Pressure specifications:
Permissible excessive operating pressure: discharge 2.5 MPa,
suction 1.2 MPa.
Maximum allowable pressure: 4.2 MPa.
Important Safety Instructions (Cont.)
Fig. 1 Fig. 2
