-6-
Connection of the inlet/drain hose
Connection of the inlet hose
1. Select appropriate type of outlet as shown in figure.
5.Check leaking
(1).Swing water inlet hose gently to confirm if it’s suitable.
(2).Turn on the water faucet and check for leak.A small amount of water might
enter the machine.You can drain this later.
2. Before installation, rid of
particles in water line that might clog the inlet valve screen.
3. Make sure that a seal washer is seating at the joint of inlet hose, then connect
the inlet hose to fauct.
seal washer
4. Make sure a seal washer seating at the joint of inlet hose, then connect
the inlet hose to the water inlet valve.
seal washer
joint
water inlet valve
running water through both faucet and inlet hose, to get
be resulted.
be resulted.
