10
Slide the heat shrink tubing as far as it will go on to the battery terminals and
apply heat. What you see in the picture is a professional heat tool. The
appearance of red-hot on the battery surface around the wire is a reflection of
light – not heat! It doesn’t take much to shrink the tubing. A match or lighter will
work very well.
11
This is what solder joints should look like when complete.
Crystalyte Hub Motor Kit Home Assembly Guide
2006 EV Depot, a Priority Fulfillment and Distribution, LLC Company 14 of 20
