EvaKool DOWN UNDER Series Service Manual

DOWN UNDER SERIES
14
POWER CONSUMPTION:
The engineering of this refrigeration system was done in-house here at Evakool, the system
is very well balanced incorporating extremely eicient rollbond evaporators with an air
cooled copper and aluminum finned condenser and the right amount of insulation to
give perfect cooling and maximum literage in the fridge compartments. We are extremely
happy with the performance of the refrigerator with all of our Australian made fridges
being true tropical rated.
DU47 Down Under 47 Litre - Climate Class ‘T’ Rated
Ambient
Temperature
Speed Voltage
Fridge
Temp Set
Freezer
Temp Set
Amps consumed
per hour
24°C ECO 12.8 Volts -16°C 1.5
32°C ECO 12.8 Volts -16°C 1.95
38°C ECO 12.8 Volts -16°C 2.38
43°C ECO 12.8 Volts -16°C 2.97
24°C MAX 12.8 Volts -16°C 1.56
32°C MAX 12.8 Volts -16°C 2.11
38°C MAX 12.8 Volts -16°C 2.55
43°C MAX 12.8 Volts -16°C 3.27
24°C ECO 12.8 Volts 2°C 0.7
32°C ECO 12.8 Volts 2°C 1
38°C ECO 12.8 Volts 2°C 1.32
43°C ECO 12.8 Volts 2°C 1.64
24°C MAX 12.8 Volts 2°C 0.73
32°C MAX 12.8 Volts 2°C 1.08
38°C MAX 12.8 Volts 2°C 1.4
43°C MAX 12.8 Volts 2°C 1.76
Test Conditions: 12.8V DC. Controlled test room. Set ambient temperatures. 24hr test period.
Fridge remained closed. No product inside. Fridge 2°C. Freezer -16°C.
