EvaKool RV25 User Manual

EVAKOOL RV25, RV35, RV62, RV82
DC Compressor Portable Fridge/Freezer
Operation Manual
3 | P a g e
LED Display
Fault LED
Turbo LED
3. Operation
• Power ：
：：
： DC (12 and 24 Volt) or AC (240 Volt)
• Cable Length Specification
The DC cables must have a suitable cross-section for their length (measured from the battery
to the unit), according to this table:
Cable Thickness 12V Max Cable Length 24V Max Cable Length
[mm2] AWG [m] [ft.] [m] [ft.]
2.5 14 2.5 8 5 16
4 12 4 13 8 26
6 10 6 20 12 39
10 8 10 33 20 66
LCD Control Panel
Temperature Controls
TURBO SWITCH ON/OFF SWITCH

EvaKool RV25 Specifications

General

Brand	EvaKool
Model	RV25
Category	Freezer
Language	English
