To connect remote to headrail
• Choose channel required on remote if a multi-channel remote.
• Press button located on motor for around 2 seconds – Motor will shunt – release
button after 1
st
Shunt.
• (This button is located in a small hole next the wire coming out of the motor)
• You will also get this shunt when you first connect the battery to the motor.
• Within 10s Press and Hold Stop button for around 2 seconds until the motor shunts.
• Remote is now paired to Motor.
To Set Limits
• Immediately after pairing the remote you will go into limit setting mode.
• Press the UP button once to move the blind up in Jog mode. (Short movements)
• Press and hold the UP button and the blind will move continuously.
• Press STOP when at the desired limit.
• Press and Hold STOP and UP together until the blind shunts. Upper limit is now set.
• Press the DOWN button once to move the blind down in Jog mode. (Short
movements)
• Press and hold the DOWN button and the blind will move continuously.
• Press STOP when at the desired limit.
• Press and Hold STOP and DOWN together until the blind shunts. Lower limit is now
set.
To Set middle Position
1. Move blind to position you want to be the middle and press stop.
2. Press P2 button – blind will shunt.
3. Press stop blind will shunt. Press stop again and blind will shunt.
4. Limit is now set.
5. To move to middle position, hold the stop button for around 2-3 seconds.
