40
FAN CYLINDER
F
AN SCREEN
F
AN
FAN SCREEN SUPPORT
ACCESS DOOR
COIL
COIL CONNECTIONS
FRAMED AIR
INLET LOUVER
LOUVER RETAINER
AIR INLET LOUVER MEDIA
COLD WATER BASIN
FAN & COIL CASING SECTION
PAN SECTION
eco-ATWB-E 10’ & 12’ Wide Units
