EVCO S.p.A. | EV3 300 series | Instruction sheet ver. 1.0 | Code 1043300E103 | Page 2 of 2 | PT 50/17
7
CONFIGURATION PARAMETERS
No.
PAR.
DEF.
SETPOINT
MIN... MAX.
1 SP 0 setpoint r1... r2
No.
PAR.
DEF.
ANALOGUE INPUTS
MIN... MAX.
2 CA1 0 regulation probe offset -25... 25 °C/°F
3 P0 2 type of probe
2 = J 3 = K
4 P2 0 temperature measurement unit
0 = °C 1 = °F
5 P4 1 enable regulator LED 0 = no 1 = yes
6
P5
0
value displayed
0 = regulation temperature
1 = setpoint
2 = setpoint if regulation
temperature > setpoint,
regulation temperature
if regulation tempera-
ture < setpoint – P6
7
P6
20
display unlock threshold for
P5 = 2
1... 99 °C/°F
setpoint - P6
8
P7
0
display with device switched off
0 = display off + on/standby
LED on
1 = regulation temperature
+ on/standby LED on
2 = label OFF + on/stand-by
LED off
9 P8 5 display refresh time 0... 250 s: 10
No.
PAR.
DEF.
REGULATION
MIN... MAX.
10
r0
5
setpoint differential
1... 99 °C/°F
if u0 = 3, cold mode regula-
tion differential
11 r1 0 minimum setpoint -199 °C/°F... r2
12 r2 350 maximum setpoint r1... 999 °C/°F
13
r5
1
hot or cold mode regulation
0 = cold mode
1 = hot mode
14 r11 0 setpoint offset from digital input -199... 999 °C/°F
15
r14
0
proportional band
0... 999 °C/°F
0 = PID control disabled
16 r15 60 integral action time 0... 999 s
17 r16 30 derivative action time 0... 999 s
18 r17 180 PID regulator cycle time 1... 999 s
19 r18 0 PID regulator minimum time on 0... 240 s
20 r19 0 PID regulator minimum time off 0... 240 s
No.
PAR.
DEF.
REGULATOR PROTECTIONS
MIN... MAX.
21
C1
0
minimum time between two
power-ons of regulator
0... 240 min
22
C2
0
minimum time off and delay
from power-on of regulator
0... 240 min
23 C3 0 regulator minimum time on 0... 240 s
24
C4
0
regulator activity during regula-
tion probe alarm
0 = off 1 = on
No.
PAR.
DEF.
ALARMS
MIN... MAX.
25 A1 0 temperature alarm threshold -199... 999 °C/°F
26
A2
0
temperature alarm type
0 = disabled
1 = absolute low
2 = absolute high
3 = low relative to setpoint
4 = high relative to setpoint
27 A3 0 temperature alarm delay 0... 999 min
28
A7
0
temperature alarm delay after
modifying setpoint and power-on
0... 999 min
29
A8
0
additional alarm signal delay af-
ter silencing if the condition per-
sists
0... 999 min
30
A11
2
temperature alarm switch off dif-
ferential
1... 99 °C/°F
No.
PAR.
DEF.
DIGITAL INPUTS
MIN... MAX.
31
i5
0
multi-purpose input function
0 = disabled
1 = alarm iA
2 = alarm iA + regulator off
3 = switches device on/off
4 = modifies setpoint
32
i6
0
multi-purpose input activation
0 = with contact closed
1 = with contact open
33 i7 0 multi-purpose input alarm delay 0... 999 s
No.
PAR.
DEF.
SECURITY
MIN... MAX.
34
Loc
1
enable keypad lock
0 = no 1 = yes
not available for EV3301
35
PAS
-19
password
-99... 999
do not set "149" or "161"
36
nS1
- - -
display of K1 relay start-ups in
thousands
0... 999 start-ups x 1,000
8
ALARMS
COD.
DESCRIPTION
RESET
TO CORRECT
Pr1
regulation probe alarm
automatic
- check P0
- check probe integrity
- check electrical connection
AL temperature alarm automatic check A1 and A2
iA multi-purpose input alarm automatic check i5 and i6
9
TECHNICAL SPECIFICATIONS
Purpose of the control device function controller
Construction of the control device built-in electronic device
Container black, self-extinguishin
Category of heat and fire resistance D
Measurements
75.0 x 33.0 x 39.5 mm (2 15/16 x 1 5/16 x 1
9/16 in) with fixed screw terminal blocks
75.0 x 33.0 x 52.5 mm (2 15/16 x 1 5/16 x 2
15/16 in) with plug-in screw terminal blocks
Mounting methods for the control device
to be fitted to a panel, snap-in brackets pro-
vided
Degree of protection provided by the cover-
ing
IP65 (front)
Connection method
fixed screw terminal blocks
for wires up to 2.5 mm²
plug-in screw terminal blocks
for wires up to 2.5 mm² (on
request)
JST connector
Maximum permitted length for connection cables
power supply: 10 m (32.8 ft) analogue inputs: 10 m (32.8 ft)
digital inputs: 10 m (32.8 ft) digital outputs: 10 m (32.8 ft)
Operating temperature from 0 to 60 °C (from 32 to 140 °F)
Storage temperature from -25 to 70 °C (from -13 to 158 °F)
Operating humidity
relative humidity without condensate from 10
to 90%
Pollution status of the control device 2
Compliance:
RoHS 2011/65/EC
WEEE 2012/19/EU
REACH (EC) Regulation no.
1907/2006
EMC 2014/30/EU LVD 2014/35/EU
Power supply:
230 VAC (+10 % -15 %), 50/60 Hz (±3 Hz), max. 2 VA in EV3... J7
12 VAC/DC (+10% -15%), 50/60 Hz (±3 Hz), max. 5 VA/3W in EV3... J2
Earthing methods for the control device none
Rated impulse-withstand voltage 4 KV
Over-voltage category III
Software class and structure A
Analogue inputs 1 for J/K thermocouples (regulation probe)
J thermocou-
ples
Measurement field: from 0 to 700 °C (from 32 to 999 °F)
Resolution: 1 °C (1 °F)
K thermocou-
ples
Measurement field: from 0 to 999 °C (from 32 to 999 °F)
Resolution: 1 °C (1 °F)
Digital inputs 1 dry contact (multi-purpose)
Dry contact Contact type: 5 VDC, 1.5 mA
Power supply: none
Protection: none
Digital outputs
1 with electro-mechanical relay (K1) or open collector (ac-
cording to the model)
K1 relay SPST, 5 A res. @ 250 VAC
Open collector 6... 14 VDC, 10 mA
Type 1 or Type 2 Actions Type 1
Additional features of Type 1 or Type 2 actions
C
Displays LED display, 3 digit, with function icons
Alarm buzzer Built-in
Communications ports 1 port for push encoder
N.B.
The device must be disposed of according to local regulations governing the collection
of electrical and electronic equipment.
This document and the solutions contained therein are the intellectual property of EVCO and thus pro-
tected by the Italian Intellectual Property Rights Code (CPI). EVCO imposes an absolute ban on the full
or partial reproduction and disclosure of the content other than with the express approval of EVCO. The
customer (manufacturer, installer or end-user) assumes all responsibility for the configuration of the de-
vice.
EVCO accepts no liability for any possible errors in this document and reserves the right to make any
changes, at any time without prejudice to the essential functional and safety features of the equipment.
EVCO S.p.A.
Via Feltre 81, 32036 Sedico (BL) ITALY
Tel. 0437/8422 | Fax 0437/83648
email info@evco.it | web www.evco.it
