1 NN

2 3

Meet Eve Light Switch

Power unit Frame Fixing frame

2.5 x 16 mm3.2 x 25 mm

Switching unit Switch plate

• Voltage: 230 V~ 50 / 60 Hz

• Switching capacity: 5 A

• Connection terminals: 1.5 mm

rigid wire

• External input: 230 V~

• Flush-mounted socket dimension: ø 60 mm, min. 35 mm depth

• Ambient temperature: -10 °C bis 50 °C

• Operating humidity: max. 85% rH, non-condensed

• Protection rating: IP30

• Frequency range: 2402 - 2480 MHz

• Max. RF Power (EIRP): < 4 dBm

1 Output N Neutral L Outer conductor / PhaseExternal Input
