98
Single Versus Double Pumping
To Pump One Breast at a Time:
Cap one side of the tubing adapter with the
attached cap A. Connect one tube B to the
other side.
Note: The open side must be completely capped
to ensure proper suction.
To Pump Both Breasts at the Same Time:
Ensure that both tubes B are properly
connected to the tubing adapter A.
This pump can be powered by: the supplied Evenflo AC adapter, six “AA” brand
name batteries, or the Evenflo Advanced Car Adapter (sold separately).
Note: When batteries are first installed or when adapter is first plugged in, the
pump unit will briefly turn on then o; this is normal.
Insert tubing adapter A into the port B on
the side of the pump unit C.
Note: To minimize damage to the pump unit,
always operate with a flange assembly
attached.
A
B
A
B
Attaching Flange Assembly to Pump Unit
Power Options
A
B
C
Using the AC Adapter
Using Batteries
The tubing adapter can be used to pump with one or both flanges.
WARNING
• DO NOT under any circumstances, use
this AC adapter with any other equip-
ment. Likewise, DO NOT use the adapter
from any other product on this breast
pump. If you lose the AC adapter, contact
Evenflo for a replacement.
• ALWAYS remove plug from product and
wall by pulling on the plug/housing.
DO NOT pull on the cord as this could
damage the cord.
• NEVER operate this product if it has a
damaged plug or cord.
Before using the AC adapter A, remove batteries from pump unit. Plug AC
adapter into the pump unit B then plug the adapter into 100 – 240V AC
power only (standard household outlet). For use in countries outside of North
America, a plug converter (not included) may be required. Unplug the adapter
from the outlet after each use.
A
B
A
B
WARNING
• DO NOT mix old and new batteries.
• DO NOT mix battery types; leakage, explosion and/or fire could occur.
• Remove batteries before putting product into storage.
