1. Assemble the backrest. Insert three posts A on the
headrest B into the backrest C, as shown. Make
certain the headrest locks securely into the backrest
with an audible click.
Note: This is a one-time assembly and may require
additional force to connect properly.
4. Extend the backrest adjuster. Pull the adjustment
handle E to unlock and fully extend the adjuster G.
2. Install adjustment handle. Align tabs D on
adjustment handle E with the slots F on the back
of the headrest. Press handle E against the back of
the headrest and slide upward until the tabs D lock
into place with audible clicks.
3. Attach the seat pad. Connect seat pad straps to the
hooks on the backrest assembly.
D
F
F
➚
E
Assembling Your Booster Seat
B
C
8 9
H
G
➚
5. Install the backrest assembly to the base. Slide the
backrest adjuster G into the base H. Make certain
the backrest locks into place with an audible click.
➚
E
G
➚
A
➚
➚
➚
