21
2
Route lower anchor connector assembly harness
and hook through lower anchor connector assembly
openings A on the sides of the base.
A
1
B
A
C
D
Before you begin, be sure the
vehicle is on a level surface.
Place the base A on the vehicle seat
and check the level indicator B.
The base is level when only
green (no red) is showing in
the level indicator window B.
If the indicator is red,
adjust the level of the base
by pressing adjustment
button C and lowering
the adjustment foot D.
Note: The adjustment foot
has multiple levels.
A green
filled window means
go to Step 2.
Tip!
Tip!Tip!
IMPORTANT
Not all models are equipped with an adjustment foot. If
your model does not have one, use a rolled-up towel to
adjust base level (p. 26).
