Insert both harness
straps A into the new
harness position slots.
A
5
6
Attach the appropriate
pocket on the harness
straps A (according to your
child’s size) to the splitter
plate E. Harness straps
must NEVER be routed
over the base release lever.
Tighten the harness straps by pulling the adjustment
strap F on front of the restraint.
Note: Final adjustment of the harness straps must be
completed with the baby in the child restraint.
F
E
A
Make sure both harness straps are installed
completely on the splitter plate, as shown.
Failure to properly attach the harness straps to the
splitter plate may result in a loose harness and serious
injury or death to your child.
WARNING!
DEATH or SERIOUS
INJURY can occur.
