Evenflo ExerSaucer Bouncing Barnyard - Legs and Spring Installation

3
!SSEMBLINGTHE%XER3AUCER
5. Locate three lower legs M and the base N. Align the
tabs O on the lower legs with the slots in the base,
then snap the lower legs onto the base. Repeat for all
three lower legs.
.OTE Make sure the tabs on the lower legs have
locked completely into the base, as shown, by moving
the legs from side-to-side. If they are not completely
locked in place, repeat this step until they are locked
securely.
N
O
O
O
O
N
6. Locate the tray L and three spring domes P.
Place each spring dome onto the tray over a leg open-
ing, as shown. Press the spring dome downward while
turning until it locks into place.
)FYOUDONTLINEUPTHEALIGNMENTGUIDESPROPERLYTHESPRING
DOMEMAYCOMEOFFOFTHETRAYANDCAUSEINJURY
7!2.).'
Make sure the alignment guides Q line up properly, as
shown.
P
P
P
P
L
Q
7. Turn the tray over and place three large springs R into
the center of each spring dome P.
R
R
R
P
M
